Type 3 WhiteReference# Type 3W
- Case: titanium
- Size: 44mm
- Movement: automatic winding caliber, patented ROCS 3 (Ressence Orbital Convex System)
- Function: date, days of the week, oil temperature, running seconds (180 seconds)
- Power Reserve: approximately 36 hours
- Water Resistance: 30m
- Dial: white, main and auxiliary dials revolve independently
- Caseback: sapphire crystal
- Hands: luminous, revolve independently
- Strap/Bracelet: gray cordovan
- Factory Warranty: two years
Ressence, the watch company that keeps challenging the status quo of mechanical watchmaking, is excited to announce the release of the Type 3W, a new example of the revolutionary Type 3 watch featuring the first-ever white dial in a mechanical oil filled timepiece.
The genesis of the Type 3 starts with the Ressence Orbital Convex System (ROCS), the unique in-house developed (and patented) horological unit featuring an ever-changing dial that continually orbit around one another. The purpose is a more efficient way of telling time. Information is displayed on a single surface, much like words on a piece of paper, making for improved readability. This differs than that of a traditional watch, where the hands and dial are layered on one another producing an uneven viewing plane. Composed of 215 parts, the gears in the ROCS calculates the hours, day and date, taking only the minute as a reference from the automatic movement.
First debuted in 2013, the Type 3 is the first ever oil-filled mechanical watch. A true achievement in fine watchmaking, the Type 3 is designed with a “water drop” dial effect in order to achieve crystal clear dial legibility for the wearer. To accomplish this, Ressence uses applied science. Because oil and glass share very similar responses to light refraction, the eye is tricked into momentarily losing its depth perception. The result is that the watch’s dial seems ever closer, vision of it apparently unimpeded by glass at all. The Type 3W builds upon that achievement by featuring the first-ever white dial in an oil filled timepiece; invoking a freshness, clarity and sense of modernity that has become synonymous with the brand. The Type 3W contrasts naturally with the iconic black dial of the original Type 3.
The creation of the Type 3W and its predecessors was not without its challenges – allowing the team at Ressence to trigger its engineering and creativity neurons and further position themselves at the forefront of 21st century watchmaking. One such example was the escapement ability to oscillate properly in a viscous fluid. Ressence ingeniously designed a two-chamber system inside the Type 3 to keep the mechanical movement and oil separate. The lower chamber is comprised of the customized automatic movement and the upper chamber is hermetically-sealed with the ROCS display module bathing in 35.7ml of oil.
As such with the two-chamber system, there is no direct mechanical link between the watch’s movement and the ROCS. To accommodate this, the Type 3W uses a magnetic transmission to tie the modules together. This is done by connecting several micro-magnets to each other and positioning them in both the oil-filled upper chamber and the dry lower chamber. In order to compensate for oil volume fluctuation (dependent on temperature), the watch is fitted with a system of seven small bellows that expand and contract dependent on the increase and decrease of the oil’s volume. For a charming visual cue – the system is indirectly connected to the temperature gauge on the dial so the user can see a representation of the bellows capacity in action. The rotating, white finished discs provide a striking visual contrast to the black and gray indications (filled with extra strong Super-LumiNova), exhibiting a contemporary sensibility.
Intuitive in viewing and motion, understated in its aesthetics, the Type 3W is a perfect example of 21st century watchmaking according Ressence. The Type 3W eliminates visual complexities and superfluous elements to create a timeless object that sparks and inspires the imagination.
